Description
measurements and weight
| Code | WLL | Weight | Ident no. | Download 3D | |||||
|---|---|---|---|---|---|---|---|---|---|
| [t] | ød [mm] |
a [mm] |
b [mm] |
t [mm] |
[kg] | ||||
| TBGV 1-6 | 1,12 | 13 | 54 | 25 | 84 | 0,4 | 0321106000 | ||
| TBGV 1-8 | 2 | ,016 | 70 | 34 | 111 | 0,7 | 0321108000 | ||
| TBGV 1-10 | 3,15 | 18 | 85 | 40 | 136 | 1 | 0321110000 | ||
| TBGV 1-13 | 5,3 | 22 | 115 | 50 | 178 | 2 | 0321113000 | ||
| TBGV 1-16 | 8,0 | 26 | 140 | 65 | 218 | 3,6 | 0321116000 | ||
| TBGV 1-18 | 10,0 | 32 | 150 | 70 | 239 | 5,5 | 0321118000 | ||
| TBGV 1-22 | 15,0 | 36 | 170 | 75 | 274 | 8 | 0321122000 |
