Description
measurements and weight
| Code | WLL | Weight | Ident no. | Download 3D | |||||
|---|---|---|---|---|---|---|---|---|---|
| [t] | a [mm] |
b [mm] |
c [mm] |
t [mm] |
[kg] | ||||
| MVK 6 | 1,8 | 44 | 105 | 43 | 81 | 0,5 | 0372906000 | ||
| MVK 8 | 3,0 | 56 | 121 | 45 | 91 | 0,9 | 0372908000 | ||
| MVK 10 | 5,0 | 62 | 142 | 58 | 106 | 1,4 | 0372910000 | ||
| MVK 13 | 8,1 | 78 | 180 | 68 | 137 | 2,7 | 0372913000 | ||
| MVK 16 | 12,5 | 104 | 222 | 86 | 170 | 5,8 | 0372916000 |
